Hello, there programming enthusiast! Today we are going to learn how to count objects in an image. To count the images one has to make use of computer vision libraries. There are tones of libraries available to achieve the aim of the tutorial.
But today in this tutorial, we will be making use of the
cvlib library which is very simple, easy, and a high-level library in Python. If you don’t have the library installed yet, do the same by using the
Import Required Libraries to count objects in an image
We need a number of modules/libraries for counting the objects. The same is done in the code below.
import cv2 import numpy as np import matplotlib.pyplot as plt import cvlib as cv from cvlib.object_detection import draw_bbox from numpy.lib.polynomial import poly
We would require the following modules:
- OpenCV Module
- Numpy Module
- Matplotlib Module
- Cvlib Module
- Object detection and draw box submodules of cvlib
- We will make use of the NumPy polynomial module as well
Loading and Viewing the Image
To load an image we will be making use of the
imread function of the OpenCV library and pass the name of the image as a parameter. Make sure the image is in the same directory as the code file.
To view an image we will be using the
imshow function of the matplotlib module. The code is shown below.
img = cv2.imread('image1.jpg') img1 = cv2.cvtColor(img,cv2.COLOR_BGR2RGB) plt.figure(figsize=(10,10)) plt.axis('off') plt.imshow(img1) plt.show()
The output displayed on the screen is as follows.
Creating Boxes around various Objects
The code below will display the boxes around the objects in the image. First thing we will need is to make use of the
detect_common_objects function and pass our image object to it.
The function will return the box, label and the count of the box to be generated around an object detected. To draw the box, we would need the
draw_bbox function and pass the outputs received by the previous function to this function.
box, label, count = cv.detect_common_objects(img) output = draw_bbox(img, box, label, count)
To display the output image, we would be using the imshow function again and the output come out to be pretty accurate. The code is shown below.
output = cv2.cvtColor(output,cv2.COLOR_BGR2RGB) plt.figure(figsize=(10,10)) plt.axis('off') plt.imshow(output) plt.show()
Count objects in the image
print("Number of objects in this image are " +str(len(label)))
To count the number of objects we will count the number of labels generated by simply using the
len function on the labels list created and print the number of objects found in the picture. Here for this picture, there were 17 objects visible to the system.
The same concept was used for another image and the results are as follows. The initial image loaded is as follows.
After detecting the objects in the image the output looks something like this. The program detected the four dogs present in the image.
Congratulations! Now you can try out any random image and check out how many different objects are present in the image. Try it out yourself!
Thank you for reading!
